How to Choose the Right SoC for Your Application?

In this blog, we’ll go over the important things to think about when selecting a system-on-a-chip (SoC), along with some illustrations of various SoCs and their uses.

How to Choose the Right SoC for Your Application?

System on Chip Basics

How to Choose the Right SoC for Your Application

System on a chip (SoC) devices are semiconductor chips that have embedded parts that allow the chip to work independently of other systems. They consist of a CPU or microcontroller, memory, and an interface. Wireless communications systems on a chip (SoC) and radio frequency (RF) technologies are used in cell phones. They also include text messaging, input/output (I/O) logic control, multimedia, and Internet access.

Different types of SoCs

  • System-in-package (SiP): SoCs integrated with additional components, like memory and storage, are known as SiPs. High-density applications such as tablets and smartphones commonly make use of them.
  • System-on-module (SoM): In a SoM, a carrier board and a SoC are integrated. The most common applications for them are embedded ones, such as robotics and industrial automation.
  • Application-specific integrated circuits (ASICs): SoCs that have been specially created and optimized for a specific use are known as ASICs. They are typically found in high-end devices such as smartphones and servers.
  • Field-programmable gate arrays (FPGAs): These programmable SoCs are designed to be configured for a wide range of uses. Although they are mostly used in development and prototyping, they can also be used in production settings.

Examples of SoCs

  • MediaTek Dimensity 9000: Tablets and smartphones in the midrange typically use the MediaTek Dimensity 9000 SoC. It offers a good compromise between power consumption and performance.
  • Samsung Exynos 2200: The Samsung Exynos 2200 SoC powers the Samsung Galaxy S22 smartphone. Both performance and power usage are efficient.
  • Apple A15 Bionic: The Apple A15 Bionic SoC is used in both the iPad mini 6 and the iPhone 13. This is one of the strongest SoCs on the market.
  • Qualcomm Snapdragon 8 Gen1: This SoC is found in high-end smartphones and tablets. It boasts a powerful CPU, an abundance of RAM, and state-of-the-art graphics capabilities.

How to choose an SoC device?

When choosing a SoC for your application, there are a number of factors to consider, including:

  • Consider the necessary screen size: Size is the first consideration while selecting your SoC player. If the devices you find support every feature you require but only come with 75-inch screens when you really want a 40-inch screen, you’ll be back where you started.
  • Think about the qualities you need: Not every feature is supported by every SoC chipset. Some considerations to make while analyzing characteristics are.
    • HTML5 support: Is HTML5 content displayable in your player? Does it have the processing power to smoothly deliver your material, including animation and other media?
    • Support for HDMI input: Certain SoCs enable you to display a zone of content that is retrieved from the HDMI-1 source on your player using your digital signage CMS. Essentially, content from another device can be shown on a top box or cable box.
    • Native portrait: You can always flip your screen to the side and publish your content in portrait orientation if that’s how it was intended to be seen. However, your screens will need to know which side up they are if you want to display HTML5 content or web pages.
  • Speak with your reseller: You should be able to find a device that satisfies all of your needs as long as you know what features you need (or may need in the future) and what size screen you have. After then, your choices will be restricted to what is available. Most of the time, your reseller will have a preferred piece of gear, but it’s crucial to consider all of your options and choose the one that best meets your needs.
  • Examine the expenses: At this point, you should consider the price range that your preferred SoC will fall into. If this is too expensive, you may have to settle for a model with fewer features or a smaller screen.

Here are some more recommendations for choosing the right SoC:

  • In the future, strive to expand your application. If you plan to add features or capabilities to your program in the future, you will need to choose a SoC that can handle those updates.
  • Consult with other programmers who have worked with the SoC that interests you. They can provide you with useful details regarding the security, performance, and power consumption of the SoC.
  • Examine reviews on the SoC before making a purchase. This will allow you to do an impartial assessment of the SoC.

By following the recommendations in this blog, you may choose the optimal SoC for your application and ensure that it meets your requirements for performance, power consumption, cost, and security.

Leading SoC manufacturers

  • Apple: The company leads the industry in SoC production for its own products, which include the iPhone and iPad. Their A-series SoCs are known for their high performance and power efficiency.
  • NVIDIA: The leading provider of System-on-a-Chip (SoC) for gaming consoles such as the Xbox Series X and PlayStation 5, is NVIDIA. Tegra SoCs are also utilized by a few premium tablets and smartphones.
  • Intel: Intel is a prominent manufacturer of System-on-a-Chip (SoC) for laptops and other personal computers. Their Core i3, Core i5, and Core i7 SoCs are used in many devices.
  • AMD: AMD is the industry leader in producing SoCs for laptops and other personal computers. Their Ryzen 3, Ryzen 5, and Ryzen 7 SoCs are used in many devices.
  • MediaTek: MediaTek is yet another leading source of SoCs for tablets and smartphones. Their Dimensity SoCs are designed for high-end and ultra-high-end devices, while their Helio SoCs are intended for mid-range and low-end devices.
  • Renesas: Renesas is a top supplier of SoCs for use in automotive applications. Cars, trucks, and buses are just a few of the vehicles that use their R-Car SoCs.
  • NXP Semiconductors: NXP Semiconductors is a well-known manufacturer of System-on-a-Chips (SoCs) for a variety of applications, including industrial, automotive, and networking. Their i.MX SoCs are used in many different devices.
  • Samsung: Samsung is a well-known manufacturer of system-on-a-chips (SoCs) for mobile devices, including tablets, smartphones, and other gadgets. This firm makes Exynos SoCs for high-end phones, whereas Exynos Mongoose SoCs are designed for mobile gaming.

And you can check out Ampheo Electronics to have a better understanding of SoC and more.

Conclusion – Choose the Right SoC

SoCs are an incredibly versatile technology that may be utilized to build a huge range of electrical products. The performance, power consumption, pricing, and security needs of your application should all be taken into account when selecting a system-on-a-chip (SoC). You may make sure your application fulfills your needs and select the appropriate SoC by using the advice in this article.
